10 Pack McCallum Stainless Steel Offset Interfold Hinge Satin S801
S261

• 10 x Hinge

Application:

• Suitable for aluminium doors in medium usage situations.
• Offset Knuckle

Specification:

• Material: Stainless Steel 304 Grade
• Bearings: 2 Stainless Steel Off-Cage Ball Bearings
• Pin Dia: 6.9mm - Stainless Steel 304 Grade
• Knuckle: Round
• Endcaps: Pressed-in interference knurled fit. Stainless Steel 304 Grades Steel

Installation Guide Only:

• Door Thickness: Minimum 35mm
• When using a door closer, we recommend a minimum of 3 hinges be used, with the top hinge located as high as possible. For excessive usage, a fourth hinge may be required.
• Standard Door: 2040 (Height) x 820 (Width)

Fixing:

• Fastening Screws supplied
• Pop rivets are not recommended.

Finish:

• Satin finish Stainless Steel
