Brava Metro Entrance Lever Set Fire Rated 70mm SC Keyed To Differ EV6000SC70

Product image 1
1 / 2

Brava Metro Entrance Lever Set Fire Rated 70mm SC Keyed To Differ EV6000SC70

Brava Metro Entrance Lever Set Keyed to Differ
EV6000SC70

  • BRAVA Metro EV6000 series commercial grade entrance leverset with external clutching lever.

Entrance function:

  • Outside key unlocks outside clutching lever.
  • Inside lever free at all times,push button locks outside lever.

Additional info:

  • Clutching lever feature to prevent forcing.
  • Screw post to prevent lock rotation are removable.
  • Charlotte lever design.
  • Cylindrical fixing.
  • Silca LW5 profile 6 pin cylinder.
  • Incorporates the popular PD 8221 barrel.
  • Compatible with most restricted keying systems.
  • Boxed and colour coded.
  • Keyed to differ.
  • 2 keys supplied.
  • Fire rated.
  • Finished in satin chrome.

Features:

  • Door thickness: 35-51mm
  • Backset: 70mm
  • Max. knob projection: 72.5mm (distance may not include turnsnib)
  • Strike: 28mm x 70mm x 2mm
  • Latch: 70mm (12.7mm throw)
  • Latch face plate: 57mm x 25mm
  • Cylinder: LW5 profile
  • Door handing: Non-handed levers
  • Rose: 85mm
  • Successfully tested up to 4 hours (depending on type of doorset) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.

Brava Metro Entrance Lever Set Keyed to Differ
EV6000SC70

  • BRAVA Metro EV6000 series commercial grade entrance leverset with external clutching lever.

Entrance function:

  • Outside key unlocks outside clutching lever.
  • Inside lever free at all times,push button locks outside lever.

Additional info:

  • Clutching lever feature to prevent forcing.
  • Screw post to prevent lock rotation are removable.
  • Charlotte lever design.
  • Cylindrical fixing.
  • Silca LW5 profile 6 pin cylinder.
  • Incorporates the popular PD 8221 barrel.
  • Compatible with most restricted keying systems.
  • Boxed and colour coded.
  • Keyed to differ.
  • 2 keys supplied.
  • Fire rated.
  • Finished in satin chrome.

Features:

  • Door thickness: 35-51mm
  • Backset: 70mm
  • Max. knob projection: 72.5mm (distance may not include turnsnib)
  • Strike: 28mm x 70mm x 2mm
  • Latch: 70mm (12.7mm throw)
  • Latch face plate: 57mm x 25mm
  • Cylinder: LW5 profile
  • Door handing: Non-handed levers
  • Rose: 85mm
  • Successfully tested up to 4 hours (depending on type of doorset) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.
$70.76
Brava Metro Entrance Lever Set Fire Rated 70mm SC Keyed To Differ EV6000SC70—
$70.76

Description

Brava Metro Entrance Lever Set Keyed to Differ
EV6000SC70

  • BRAVA Metro EV6000 series commercial grade entrance leverset with external clutching lever.

Entrance function:

  • Outside key unlocks outside clutching lever.
  • Inside lever free at all times,push button locks outside lever.

Additional info:

  • Clutching lever feature to prevent forcing.
  • Screw post to prevent lock rotation are removable.
  • Charlotte lever design.
  • Cylindrical fixing.
  • Silca LW5 profile 6 pin cylinder.
  • Incorporates the popular PD 8221 barrel.
  • Compatible with most restricted keying systems.
  • Boxed and colour coded.
  • Keyed to differ.
  • 2 keys supplied.
  • Fire rated.
  • Finished in satin chrome.

Features:

  • Door thickness: 35-51mm
  • Backset: 70mm
  • Max. knob projection: 72.5mm (distance may not include turnsnib)
  • Strike: 28mm x 70mm x 2mm
  • Latch: 70mm (12.7mm throw)
  • Latch face plate: 57mm x 25mm
  • Cylinder: LW5 profile
  • Door handing: Non-handed levers
  • Rose: 85mm
  • Successfully tested up to 4 hours (depending on type of doorset) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.
